Corrugated Plastic Sign
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board
Corrugated Plastic Advertising Sign Board

1.    Material: Polypropylene(PP)

2.    Thickness: 3mm, 4mm, 5mm, 6mm

3.    Weight: 500 - 1200gsm

4.    Size: 18x24in, 4x8ft

5.    Surface: Double sides corona treatment

6.    Print: Screen printing, Digital printing


   Flute Space

   3mm, 4.2mm



   Tolerances

   Value

   Dimensional tolerance along the flutes or length

   0/+ 20mm

   Dimensional tolerance across the flutes or width

   +/- 2mm


   Technical Characteristics

   Value

   Softening temperature

   144°C

   Crystaline melting point

   166 - 175°C

   Flash ignition temperature

   350°C

   Self ignition temperature

   380°C

   Calorific value

   11,000cal.kg

   Specific heat

   0.46 cal/gm°C

   Limited oxygen index

   0.174 – 0.180

   Burn rate

   5.3 – 8.2 cm/min



   Treatments


   Corona discharge

  Enables flexographic and screen printing – min 50 Dynes

   Anti static

  10^6 - 10^9, Incorporated into the bulk polymer for maximum.18-24 months expected life even after washing

   UV stabilised

  Extends product life when used outdoors

   Flame retardant (UL94)

   V0, V1, V2
